unit style
|
|
CMA200DN
|
|
Cooling capacity
|
kW
|
700
|
|
Input power when cooling
|
kW
|
222
|
|
Nominal absorbed current of unit
|
A
|
420
|
|
COP
|
kW/kW
|
3.15
|
|
Power supply
|
V/P/HZ
|
3P/380V/50HZ
|
|
Max absorbed current of unit
|
A
|
540
|
|
Control type
|
|
SIEMENZ PLC
|
|
Refrigerant type
|
|
R407C
|
|
Discharge volume
|
kg
|
218
|
|
Refrigerant control type
|
|
THERMAL EXPANSION
|
|
Compressor type
|
|
semi-hermetic screw type
|
|
Compressor number
|
set
|
2
|
|
Compressors power input
|
kW
|
101×2
|
|
Compressors absorbed current
|
A
|
178×2
|
|
Capacity stage
|
|
12.5~100%
|
|
Evaporator type
|
|
shell and tube type
|
|
Water temperature IN/ OUT
|
℃
|
12∕7
|
|
Water Flow user side
|
m3/h
|
120.4
|
|
Diameter of water pipe
|
DN
|
DN150
|
|
Total water DP
|
kPa
|
68
|
|
Outdoor temperure(design)
|
℃
|
35
|
|
Unit working temperature range
|
℃
|
21~43
|
|
Condenser
|
|
|
|
Condenser type
|
|
copper tube+aluminum fin
|
|
Fan type
|
|
axial type
|
|
Fan number
|
|
16
|
|
Air flow
|
m3/h
|
20000×16
|
|
Fans power input
|
kW
|
1.25×16
|
|
Fan absorbed current
|
A
|
4×16
|
|
Heating recovery
|
|
|
|
Heating recovery capacity
|
kW
|
280
|
|
Water temperature of IN/OUT
|
℃
|
40/45
|
|
Water flow
|
m3/h
|
48.2
|
|
Water DP
|
kPa
|
50
|
|
Diameter of water pipe
|
DN
|
80
|
|
Unit dimensions &Weight
|
|
|
|
Height
|
mm
|
2500
|
|
Length
|
mm
|
8160
|
|
Depth
|
mm
|
2232
|
|
Unit weight
|
kg
|
8600
|
|
SAFETY DEVICE & ACCESSORY
|
|
|
|
Pressure switch(High, Low); Fusible Plug; Electronic over current relay
|
|
|
|
Discharge temp.thermistor; Freeze protetion thermistor; Safety vavle
|
|
|
|
|
|
f
|
